Ultrasonic Liquid Flow Meter Sensor Module Flow Control Sensors 5V Digital Output

Name: Ultrasonic Liquid Flow Meter Sensor Module Flow Control Sensors 5V Digital Output
Brand: AUDIOWELL
Price: 350.00 USD

China Ultrasonic Liquid Flow Meter Sensor Module Flow Control Sensors 5V Digital Output wholesale

Model Number : FS0021

Place of Origin : Guangdong, China

Brand Name : AUDIOWELL

MOQ : 100 pieces

Price : $350.00/pieces >=100 pieces

Series : Flow control sensor module

Features : control water flow

Mounting Type : Pipe type

Description : Flow control sensor module, Flow Control Sensor Module

Type : Liquid Flow Sensor

Usage : Control water flow

Theory : ultrasonic

Operating Voltage : DC 24 V

Automatic mode flow control accuracy : >3.3L/min: ±10%; ≤3.3L/min: ±0.33 L/min

Action time interval of ball valve : 30 s

Accuracy : <±5%

Flow regulation range : 1~10 L/min

Ultimate operating pressure : 1.6 MPa

Update frequency of traffic data : 4 Hz

Communication mode : 4G

Operating temp : 0.1~+40℃

Operating humidity : <90%

Contact Now

AUDIOWELL 5V Digital Output Ultrasonic Flow Meter Flow Control Sensor Module Water Flow Controller

Product Description

Ultrasonic Liquid Flow Meter Sensor Module Flow Control Sensors 5V Digital Output

Specification

Operating Voltage	DC24V
Power Interface	2-core waterproof quick connect connector
Flow Control Accuracy In Automatic Mode	±10% (flow control>3.3L/Min) ±0.33L/Min(flow control≤3.3L/Min)
Ball Valve action Time Interval	≈30 s
Pressure Loss	≤40KPa
Flow Metering Accuracy	＜±5%
Flow Regulation Range	1~10 L/min
Maximum Allowable Working Pressure	1.6 MPa
Update Frequency of Traffic Data	4Hz
Communication Mode	4G
Operating Temp	0.1～+40℃
